Polyester 12 Strand

Polyester 12-Strand

Polyester 12 Strand has the lowest stretch and highest strength of all polyester constructions. Its torque free braided construction provides easy handling and prevents kinks and hockles. Polyester 12 Strand is delivered standard with a clear polyurethane finish and is easily spliced using a simple lockstitch type splice. The largest market for this rope, transmission stringing lines, typically consists of sets of ropes in four different colors.

Close-up of nylon double braid rope showing tight woven pattern and durability.

Polyester 12 Strand Tech Sheet

Features / Benefits

Low stretch
High strength
Soft hand
Torque free
Easy splicing

Applications

Transmission stringing lines
Underground pulling lines
Lifting slings
Adjustable transformer slings

Nominal Diameter (inches)	Size (circ in.)	Approximate Weight (lbs/100ft)	Minimum Tensile Strength Spliced Rope (lbs)	Minimum Tensile Strength ISO Unspliced Rope (lbs)
3/8	1-1/8	4.2	6,100	6,800
7/16	1-1/4	6.3	9,000	10,000
1/2	1-1/2	8.5	10,900	12,100
9/16	1-3/4	10.1	13,600	15,100
5/8	2	13.1	17,500	19,400
3/4	2-1/4	17.2	21,900	24,300
7/8	2-3/4	25.8	28,500	31,700
1	3	34.5	41,000	45,600
1-1/8	3-1/2	40	47,500	52,800
1-1/4	3-3/4	44.5	56,700	63,000
1-5/16	4	53.1	59,800	66,400
1-1/2	4-1/2	69	69,800	77,600
1-5/8	5	82.5	83,000	92,200
1-3/4	5-1/2	96.1	98,000	108,900
2	6	117	120,000	133,300

Nominal Diameter (mm)	Size (circ in.)	Approximate Weight (kg/100m)	Minimum Tensile Strength Spliced Rope (tonnes)	Minimum Tensile Strength ISO Unspliced Rope (tonnes)
9	1-1/8	6.3	2.8	3.1
11	1-1/4	9.4	4.1	4.5
12	1-1/2	12.6	4.9	5.5
14	1-3/4	15	6.2	6.9
16	2	19.5	7.9	8.8
18	2-1/4	25.6	9.9	11.0
22	2-3/4	38.4	12.9	14.4
24	3	51.3	18.6	20.7
28	3-1/2	59.5	21.6	24.0
30	3-3/4	66.2	25.7	28.6
32	4	79	27.1	30.1
36	4-1/2	102.7	31.7	35.2
40	5	122.8	37.7	41.8
44	5-1/2	143	44.5	49.4
48	6	174.1	54.4	60.5
